Main Features
- Easy Operation: Feeding and receiving materials by clicking the control panel. One key to switch from feeding to receiving materials.
- Accuracy Detection: High sensitivity indicator and ball screwdriver to increase the correction precision & speed.
- Intelligent Control: Distance sensor ensures materials feeding automatically.
- Roll limit Panel: Limit fabric roll to the diameter from 3.93″ to 27.5″ (100-700 mm), and length up to 70.8″ (1800 mm).
Technical Parameters:
| Roll Width: | 70.86″ (1800 mm) |
| Roll Diameter: | 3.93″- 19.68″ (100-500 mm) |
| Max Loading: | 150 kg |
| Correction Range: | 0-7.87″ (0-200 mm) |
| Transmission: | Ball screw driver |
| Working Environment: | 5-40 ℃ ; Humidity: 5%~80% |
| Equipment Power： | 0.2 KW |
| Power Supply: | 220 V/60 Hz |
| Weight: | 882 lbs (400 kg) |
| Dimension: | 95″ x 29″ x 32″ (2399 x 725 x 816 mm) |
