Main Features
- IPG Laser Resonator.
- High Rigidity Enhanced Aviation Aluminum Gantry.
- Rack and pinion structure, servo drive, secondary annealing treatment of high rigid welding frame with high accuracy and stability.
- Professional laser cutting software with graphic layout and sharp corner smoothing functions, fast piercing & cutting.
- Space Saving: no exchange table.
Technology Specifications
- Working Area: 5′ x 10′ (1,525 mm x 3,050 mm)
- Optional Working Area: 5’ x 20’ (1,525 x 6,100 mm)
- Z-axis Travel 4.7″ (120mm)
- Laser Resonator: IPG 1000 W/ IPG 1500 W / IPG 2000 W
- Continuous Wave fiber laser, 1.07 um wavelength
- Beam Quality: <0.373 mrad
- Laser Head: RayTools (Auto Focus)
- Control System: CypCut BCS 100
- Cooling System: TeYu CWFL1000, CWFL-1500, CWFL-2000 or Comparable
- Driving System: Servo Motors
XYZ Servo Motors: Schneider or Delta Y 2x1500W, X 1x1000W, Z 1x400W - High-Quality Rack and Pinion Guide Rails
