Main Features
- Full Protection from fiber laser through the large observation window
- Deep engraving and 3D engraving
- Large marking field up to 600 mm x 600 mm (24″ x 24″)
- Directly engrave and mark on curved surface.
- Extremely fast speed and high precision
- Motorized Z-axis up and down
- Engraving Applications: metals, stone, ceramic, plastic and all types of alloys
- Two Red Dots for easy focal length adjustment
- Visible Red Laser for alignment and preview
- FREE Desktop and operation software
- FREE one pair of laser protection goggles
- No moving parts, no consumables, maintenance free
- Two year warranty on all parts and remote service
Technology Specifications
| Laser Generator: | IPG 100W |
| Laser Source Life Time: | 100,000 + hours |
| Standard Working Area: | 24” x 24” (600 mm × 600 mm) |
| Marking Speed: | up to 7000 mm/s |
| Laser Wavelength: | 1.06 um |
| Beam divergence: | 0.3 mrad |
| Focused beam diameter: | <=20 um |
| Min. line width: | 0.02 mm |
| Min letter size: | 0.15 mm |
| Marking depth: | 0.03-0.08 mm |
| Power Supply: | 110 V / 60 Hz |
| Cooling: | Air-cooled, no extra cooling needed |
| Dimensions: | 72 x 48 x 40 |
| Net Weight: | 800 lb |
3D dynamic focus system
With a 3D dynamic focus system, a machine laser head has been developed with a unique optical design and software algorithm. As a result, our Galvo laser marking machine has more capacity to process sophisticated marking and engraving.
– Motorized Z-Axis will automatically adjust the laser head to ensure that the laser beam is always at the accurate position for marking and engraving. High-efficiency productions and precision engraving will be assured.
– Large work area up to 600mm x 600 mm (24″ x 24″)
– Curved surface engraving
– Deep and 3D engraving
