BesCutter HyRobot 1.5KW 3D Robot IPG Fiber Laser Metal Cutting Machine
$250,000.00 $350,000.00
PRODUCT INTRODUCTION
- Adopts gantry structure, flying optical path design, the laser head move around while the product is fixed.Â
- High precision industrial robot, equipped with a mature robot control system: high accuracy, stability, and reliability.
- IPG 1.5 KW laser resonator (YLR-1500-K)
- US Lasermech 3D laser head:Â compact design, stable dynamic follow-up system, good cutting ability.
 – Robot installation basement: There is a collision induction device that connects to the laser cutting head and robot.
– Fiber collimating beam expander (cutting, welding):Â 125 mm standard focal length.
– Driving system: It helps the cutting nozzle to move to follow the product surface.
 – Fixed parts-nozzle: Block the dust and scrap.
- Safety protection housing, using safety interlocking design.
_________________________________________________________________
MACHINE VIDEO
INDUSTRIAL ROBOT TECHNICAL PARAMETERÂ
| Industrial robot brand | Staubli |
| Robot model | RX160L |
| Working area | 59″ x 78.74″ (1500 x 2000 mm) |
| Max load | 61.5 lbs (28 kg) |
| Rated load | 30.5 lbs (14 kg) |
| Re-positioning accuracy | ±0.05 mm |
| Wingspan | 2010 mm |
| Axis-1 | ±160˚ |
| Axis-2 | +147.5Ëš/-130Ëš |
| Axis-3 | ±145˚ |
| Axis-4 | ±270˚ |
| Axis-5 | +140Ëš/-115Ëš |
| Axis-6 | ±360˚ |
| Laser Resonator | IPG 1.5 KWÂ (Germany Brand) |
| Laser head | USÂ LaserMech 3D laser head |
| Machine Weight | 555.57 lbs (252 kg) |
