Main Features
- Unparalleled versatility for cutting various metals, including low carbon steels, stainless steels, galvanized sheets, as well as some high reflective metals, such as aluminum
- Long Durability (Cast Aluminum Beam, High-Temperature Annealing Solid Machine Bed)
- IPG Laser Generator
- Fully Protected Enclosure
- Slide Out Table for easy load/unload
Technology Specifications
- Working Area: 51″ x 51 ” (1300 mm x 1300 mm)
- Z-axis Travel: 4.7″ (120 mm)
- Continuous Wave fiber laser, 1.07 um wavelength
- Laser Wattage: 1000 W/ 1500 W/ 2000 W/ 3000 W
- Beam Quality: <0.373 mrad
- Positioning Accuracy: <= 0.05 mm/m
- Max. no load speed: 2362 inch/min (60m/min)
- Machine Power Supply: Three Phase 208V, 240V or 480V
- Power consumption: 10-30 kW (various by laser wattage)
- Dedicated USA technical support from qualified technicians and engineers
- Gross weight: 5,500 lbs
- Air-Assist: Oxygen or Nitrogen
- Driving System: Servo Motors XYZ Servo Motors: Schneider or Delta, Y 2x850W, X 1x750W, Z 1x400W
