Industrial Refrigerated Water Chiller CWFL-1500 For Fiber Laser 1500W


$2,593.00

MAIN FEATURES

  • With environmental refrigerant;
  • ±5℃ precisely temperature control;
  • The intelligent temperature controller has 2 control modes, applicable to different applied occasions; with various setting and display functions
  • Dual temperature to satisfy different needs of the fiber laser device and the optics;
  • With Ion adsorption filtrating and test, functions conform to fiber laser device operating requirements
  • Multiple alarm functions: compressor time-delay protection, compressor overcurrent protection, water flow alarm, and over high / low-temperature alarm;
  • Multiple power specifications; CE approval; RoHS approval; REACH approval;
  • Optional heater and water filter.
Model: CWFL-1500BN
Voltage: AC 1P 220V Tank Capacity: 15L
Frequency: 60 Hz  Inlet and Outlet: Rp 1/2″ + Pp 1/2″
Current: 3.4 ~ 14A Lift: 53M
Machine Power: 2.76 KW Rated flow: 2 L/min +> 15 L/min
Electric assisted power: 400W + 600W N.W. 72 Kgs   (158 lbs)
Precision:  ±0.5°C G.W. 82 Kgs  (181 lbs)
Reducer: Capillary Dimension 70 x 47 x 89 cm (LxWxH)

(27.6” x 18.5” x 35”)

Pump power: 0.75 KW Package dimmension 74 X 61 X 104 cm (LxWxH)

(29.1” x 24” x 40.9”)
