MAIN FEATURES
- With environmental refrigerant;
- ±5℃ precisely temperature control;
- The intelligent temperature controller has 2 control modes, applicable to different applied occasions; with various setting and display functions
- Dual temperature to satisfy different needs of the fiber laser device and the optics;
- With Ion adsorption filtrating and test, functions conform to fiber laser device operating requirements
- Multiple alarm functions: compressor time-delay protection, compressor overcurrent protection, water flow alarm, and over high / low-temperature alarm;
- Multiple power specifications; CE approval; RoHS approval; REACH approval;
- Optional heater and water filter.
Model: | CWFL-1500BN | ||
Voltage: | AC 1P 220V | Tank Capacity: | 15L |
Frequency: | 60 Hz | Inlet and Outlet: | Rp 1/2″ + Pp 1/2″ |
Current: | 3.4 ~ 14A | Lift: | 53M |
Machine Power: | 2.76 KW | Rated flow: | 2 L/min +> 15 L/min |
Electric assisted power: | 400W + 600W | N.W. | 72 Kgs (158 lbs) |
Precision: | ±0.5°C | G.W. | 82 Kgs (181 lbs) |
Reducer: | Capillary | Dimension | 70 x 47 x 89 cm (LxWxH)
(27.6” x 18.5” x 35”) |
Pump power: | 0.75 KW | Package dimmension | 74 X 61 X 104 cm (LxWxH)
(29.1” x 24” x 40.9”) |
