ALL SYSTEM INCLUDED BESCUTTER VERSA STAR TWIN XL 63″X40″ CO2 LASER CUTTER & ENGRAVER 150W – DOUBLE HEAD | STOCK AVAILABLE | FAST DELIVERY
Price range: $17,950.00 through $20,950.00
Full List of Specifications (PDF)
TECHNICAL SPECIFICATIONS:
| Laser Power: | Double 150 W Standard, (180W or 200W Optional) |
| Laser Tube Type: | ECO2, CO2 Sealed Glass Laser Tube, 10.6 μm wavelength |
| Laser Tube Lifetime: | 10000 hours |
| Power Supply: | AC 110V (±10%) 60HZ |
| Working Area: | 63″x40″ (1,600 mm x 1,100 mm) |
| Working Platform: | Knife-blade and Honeycomb |
| Z-Axis Displacement: | ±12in (±300 mm) |
| Max Moving Speed: | 28 in/s (700 mm/s) |
| Operation Mode: | Control panel |
| Machine Dimensions: | 72″ x 56″ x 46″ (1820 x 1420 x 1150 mm) |
| Gross Weight: | 1300 lb (600kg) |
| Class: | Class 4 Laser |
MACHINE CONFIGURATION:
| Controlling System: | RuiDa Controller RDC6442S·B(EC) |
| Software: | RDWorks / Compatible LightBurn® |
| Motion Transmission system: | Stepper Motor /Belts |
| Connection Method: | USB Cable / Data cable / Ethernet |
| Focus Lens: | 2.5″ Focal Lens |
| Software Compatibility: | Photoshop, Illustrator, CorelDraw, and AutoCAD |
| Technical support service: | Zoho Desk Technical Service (Tickets Support) |
| Max Moving Speed: | 28 in/s (700 mm/s) |
| Warranty: | One year (exclude lens and mirrors) |
| Certification: | CE, ISO |
AUXILIARY EQUIPMENT:
| Extraction System: | Exhaust Fan 1HP / 750W |
| Assistant Air: | Air Compressor Hailea 110V |
| Water Chiller: | S&A CW 5200 Industrial Refrigerated Chiller |
Materials can be cut or engraved with our CO2 Laser Systems
hine for wood – laser engraving cutting machine for acrylic -laser engraving cutting machine for cloth – laser engraving cutting machine for shoes -laser engraving cutting machine for paper – laser engraving cutting machine for glass – laser engraving cutting machine for ad – laser engraving cutting machine for stamp – laser engraving cutting machine for leather – laser engraving cutting machine for wedding card – laser engraving cutting machine for art – laser engraving cutting machine for plexiglass – laser engraving cutting machine for plastic – laser engraving cutting machine for rubber – laser engraving cutting machine for bamboo – laser engraving cutting machine for plywood – laser engraving cutting machine for PVC – laser engraving cutting machine for TPU
| Power | Double 130W STANDARD, Double 150W TUBE UPGRADE, Double 180W HIGH POWER |
|---|
