ALL SYSTEM INCLUDED BESCUTTER MIGHTY SERIES [4’X8 – 5’X10′] POWERFULL CO2 LASER CUTTER & ENGRAVER SYSTEM 260W – 300W | HEAVY DUTY | HIGH SPEED SERVO MOTORS
Price range: $31,450.00 through $36,950.00
Main Features:
- High Speed:Â Servo Motor Dual Driver
- High Precision Cutting: Rack & Pinion transmission
- High Stability:Â Integrated Aluminum Alloy Beam & Carbon Steel Frame
- Auxiliary Equipment Included:Â Exhaust fan, air exhaust pipe, industrial water chiller
Full List of Specifications (PDF)
__________________________________________________________________________________________
TECH SPECIFICATIONS:
| Laser Power: | 260W /Â 350W Optional |
| Laser Tube Type: | Combined Laser Beam System, Dual CO2 laser tube, 10.6 µm wavelength GSI |
| Laser Tube Lifetime: | 10000 hours |
| Power Supply: | Single-phase AC220V/60Hz |
| Working Area: | 48″ x 96″ ( 4′ x 8′) / 60″ x 120″ (5’x10′) optional |
| Working Platform: | Knife blade supporting table |
| Z axis displacement: | 29.5 in/s (749 mm/s) |
| Maximum Acceleration: | 0.5 G |
| Positioning accuracy: | ±0.05 / 1000 mm |
| Location Precision: | ±0.2mm / 1000 mm |
| Repeated Location Speed: |  ±0.1mm / 1000 mm |
| Transmission: | Gantry + rack & pinion + dual driver |
| Operation Mode: | Control Panel and software |
| Machine Dimensions: | 152″ x 86″ x 49″Â (3850 mm x 2190mm x 1470 mm) |
| Machine Weight: | 3968 lbs (1800 Kg) |
MACHINE CONFIGURATION:
| Controlling System: | Ruida RDC6442G |
| Electrical Control System: | Siemens and Schneider (German) |
| Operating Software: | SmartCutting STD |
| Transmission System: | Rack & Pinion |
| Focus Lens: | Φ25.4 mm; Lens 3″ with its respective aluminum barrel  and  Lens 5″ with its respective aluminum barrel |
| Reflecting Mirrors: | Φ38.1 mm; 4 mm thickness (Cooled by water) |
| Rack: | Grind Precise Rack (Taiwan) |
| Straight Rail: | Precise Heavy Load (Taiwan) |
| Traction System: | Servo Motor 750W (Taiwan) |
| Grounding: | Grounding resistance should be less than 5Ω |
| Working Environment: | Temperature: 0-104°F |
| Warranty: | One year (exclude optics and mirrors) |
| Technical Support Service: | Zoho desk technical service (Tickets support) |
AUXILIARY EQUIPMENT:
| Extraction system: | 2 Exhaust fan 812 CFM | 1100WÂ | AC 220V |
| Assistant air: | Air compressor 135W |
| Water chiller: | S&A CW 6000 industrial refrigerated chiller |
Materials can be cut or engraved with our CO2 Laser Systems
er engraving cutting machine for wood;laser engraving cutting machine for acrylic;laser engraving cutting machine for cloth;laser engraving cutting machine for shoes;laser engraving cutting machine for paper;laser engraving cutting machine for glass;laser engraving cutting machine for ad;laser engraving cutting machine for stamp;laser engraving cutting machine for leather;laser engraving cutting machine for wedding card;laser engraving cutting machine for art;laser engraving cutting machine for plexiglass;laser engraving cutting machine for plastic;laser engraving cutting machine for rubber;laser engraving cutting machine for bamboo;laser engraving cutting machine for plywood;laser engraving cutting machine for PVC;laser engraving cutting machine for TPU
| Power | 260W, 300W |
|---|---|
| Working Area | 4"x8', 5'x10' |
